Releasing designs and mill files.



Still waiting on parts to make the EPP moulding machine. It will probably be some time away before I can mould these wings.
In the meantime I have put the original designs in this torrent file.

They include the 3D model with the foil sections and twist angles. The 3D’s of the plane and packaging are organised into 1200 * 600 * 50mm EPS sheets ready to mill.

I have also included the .tap mill files to work with a Mach3 controller in mm. There is a text file at the top of the mill folder with the details of what tools to use when and how to go about it. I had not intended it to be released to the public, so if it’s a bit confusing then let me know and I’ll try clean it up to be more machinist friendly.

Cheers,

Dion.
